600 Series Insulated Rolling Service Door

The Janus International 600 Series Insulated Rolling Service Door delivers durability, thermal efficiency, and high performance. Its 24–18 gauge slats with a 24-gauge back encase a 5/8-inch polyurethane core (R-value 7.2). Sizes range from 40' x 16' to 28' x 26' with optional Windload and Miami-Dade certifications, making it ideal for industrial, commercial, and climate-controlled applications.

STANDARD FEATURES

Enclosed hood
Reduction gear chain hoist
3-piece structural steel guides
Double angle bottom bar with weather seal
2-year limited warranty
Envirocron black powder-coated guides, bottom bars and headplates

OPTIONS

Electric operation: Motorized at the push of a button (bracket available on request).
Miami-Dade certified: Impact rated 80 ft/sec and +60/-65 PSF.
Slide bolt locks: Dual steel locks for padlocks (standard on manual/push-up doors).
Vision panels: 5" x 3/4" cutouts about 3" apart, clear Lexan.
Windload: Optional up to ±50 PSF (varies by size/model).
High-cycle springs: 50,000 or 100,000 cycles.

IDEAL APPLICATIONS

Extra savings. Delivers durability and extra thermal efficiency with an insulation value of R-7.2, reducing energy consumption while maintaining internal building temperatures. From the applications video: the 600 Series insulated door is the choice for climate-controlled and energy-efficient buildings, with windload and Miami-Dade options for high-wind regions.

Climate-controlled warehouses and distribution centers
Manufacturing
Auto dealerships and car washes
Agriculture
Commercial and multi-tenant buildings
Education
Fire stations
Government and stadiums
Healthcare
Heavy equipment
High-security openings

Compare it with the 400 and 400HP in the 400 vs 400HP vs 600 service door comparison sheet, read the rolling steel door replacement ROI guide, or watch the rolling steel door applications video. Not sure which series fits? Try the door selector tool.

Download Door Sheet

PRODUCT HIGHLIGHTS

Product Type	Insulated steel or stainless steel
Model Description	Insulated Rolling Service Door
Models	624 (24/24-ga), 622 (22/24-ga), 620 (20/24-ga), 618 (18/24-ga), 622S/620S (stainless)
Insulation	5/8" injected polyurethane foam core, R-value 7.2
Slat Profile	3" Flat-265, 2-5/8" x 5/8", with 24-gauge backer
Maximum Size Width x Height	From 40' x 16' to 28' x 26' (varies by model; stainless 24' x 24')
Operation	Reduction gear chain hoist standard; electric operation optional
Standard Guides	3-piece structural steel, 3/16" minimum, with 30" service cut-out
Bottom Bar	Double angle with weather seal
Certified Options	Windload up to ±50 PSF (varies by size/model); Miami-Dade impact rated 80 ft/sec and +60/-65 PSF
Finishes	White, gray or tan topcoat; galvanized; powder coat; stainless #4
Warranty	2-year limited; paint 40-year film integrity / 25-year no-fade

The 600 Series door sheet gives sizes from 40' x 16' to 28' x 26'; the model table on the same sheet lists 26' x 30' or 31' x 20'. Confirm the maximum for your opening with Janus.

Green Janus insulated rolling service doors at a loading dock

Energy savings

Insulated Doors That Pay Back in Energy Savings

Doors that no longer seal create energy loss. Insulated rolling steel helps keep the building at temperature and keeps employees near the docks more comfortable.

Replacing 4 uninsulated dock doors with insulated rolling steel could cut HVAC energy use about 12% in a 100,000 sq ft warehouse*
That is worth an estimated $12,000 to $25,000 a year*
R-7.2 insulated slats and an STC 24 sound rating

*Illustrative examples from the Janus Rolling Steel Door Replacement ROI Guide. Actual results vary based on facility size, climate, usage frequency, labor costs and door specifications.

Get the ROI Guide Request a Quote

Compare

400, 400HP or 600: Which Service Door Fits?

The three Janus rolling service doors side by side, from the Service Door Comparison Sheet.

Compare the Janus rolling service doors
	400 SeriesHeavy Duty Service Door	400HP SeriesHigh Performance Door	600 SeriesInsulated Service Door
Built for	Extra protection	Extra speed	Extra savings
Max size	40' wide or 30' high	14' wide × 20' high	40' × 16' to 28' × 26', by model
Opening speed	Standard	Up to 24" per second	Standard
Standard cycles	25,000 (50,000 or 100,000 optional)	400,000 (600,000 optional)	25,000 (50,000 or 100,000 optional)
Insulation	No	No	R-7.2
Windload / Miami-Dade	Optional	No	Optional
DC motor	No	Yes	Optional
Counterbalance	Springs	Springless barrel	Springs

Applications

Where the 600 Series Works Best

From the Janus Rolling Steel Application Guide.

Agriculture
Auto dealership
Car wash
Commercial/multi-tenant
Education
Fire station
Government
Healthcare
Heavy equipment
High security
Manufacturing
Stadiums

Door Selector Tool

Find the Right Rolling Steel Door in Minutes

Answer eight quick questions about the building, the opening and how the door will be used. The Door Selector shows every Janus rolling steel, commercial sheet and mini door that fits, with specifications, door sheets and a quote link on every result.

Pick the building type and application
Set wind load, fire rating and daily cycles
See every matching door with specs and quote links

Open the Door Selector
